API 5L pipeline Mechanical Properties

TPCO

Specification sheet of pipeline

OCTG items abide by API


we are focused on providing OCTG products with high quality and also competitive rate. Our items are all approximately the criteria of API.
According to the criterion of API 5CT, tubes outside size is from 1.660 to 4-1/2 (42.16 mm to 114.3 mm); wall surface thickness is from 2.3 PPF to 26.10 PPF (3.57 mm to 9.52 mm). And also their steel qualities are from H40, J55, N80, N80Q, L80, L80-1, L80-9Cr, L80-13Cr, P110 and so on. The length variation is R1 (6.10-7.32 M), R2 (8.53-9.75 M), R3 (11.58-12.8 M), R2 is made use of regularly. As well as measurement variety (OD inch) of housing is 4 1/2-- 30. The steel grades are H40, J55, K55, N80, N80Q, L80, T95, P110 etc
. To fulfill the greatest global standards API 5D, Our drill pipe sizes are of 2-3/8" to 5-1/2" with annual capacity of 30 thousand metric loads. We promise to give all clients highest combined with reliability items follow the demands of API 5D. Additionally, Anson can offer drill collars from 5 feet to 32 feet, outside size in the series of 3-1/ 8 "to 11."
api 5l line pipe
And also under SSAW process, the measurement of seamless pipe is 5"-- 48", yet under process of HOT ROLLING, Hot Expanding, SSAW, the measurement is 1"/ 2"-- 24". Steel quality of line pipes are mostly GR.B, X42, X46, X56, X65, X70, X80, etc
.

According to the requirement of API 5CT, tubing outside size is from 1.660 to 4-1/2 (42.16 mm to 114.3 mm); wall density is from 2.3 PPF to 26.10 PPF (3.57 mm to 9.52 mm). To fulfill the highest international standards API 5D, Our drill pipe sizes are of 2-3/8" to 5-1/2" with annual capacity of 30 thousand metric lots. We promise to offer all customers finest top quality and integrity products adhere to the demands of API 5D.

Mechanical Properties:

Standard Grade Tensile(Mpa) Yield(Mpa) Yield Ratio Elongation(%) 0℃ Impact Akv(J) Heat Treatment
API SPEC 5L B ≥415 245~440 ≤0.80 22 ≥40 N
API SPEC 5L X42 ≥415 290~440 ≤0.80 21 ≥40 N
API SPEC 5L X52 ≥460 360~510 ≤0.85 20 ≥40 N
API SPEC 5L X60 ≥520 415~565 ≤0.85 18 ≥40 N
API SPEC 5L X65 ≥535 450~570 ≤0.90 18 ≥40 H+T
API SPEC 5L X70 ≥570 485~605 ≤0.90 18 ≥40 H+T


Chemical composition:

Standard Grade Composition(%) CEV(%)
C Si Mn P S V Nb Ti
API SPEC 5L B ≤0.16 ≤0.40 ≤1.10 ≤0.020 ≤0.010 ≤0.42
API SPEC 5L X42 ≤0.17 ≤0.40 ≤1.20 ≤0.020 ≤0.010 ≤0.05 ≤0.05 ≤0.04 ≤0.42
API SPEC 5L X52 ≤0.20 ≤0.45 ≤1.60 ≤0.020 ≤0.010 ≤0.10 ≤0.05 ≤0.04 ≤0.45
API SPEC 5L X60 ≤0.21 ≤0.45 ≤1.60 ≤0.020 ≤0.010 ≤0.15 ≤0.05 ≤0.04 ≤0.45
API SPEC 5L X65 ≤0.16 ≤0.45 ≤1.60 ≤0.020 ≤0.010 ≤0.06 ≤0.05 ≤0.06 ≤0.45
API SPEC 5L X70 ≤0.16 ≤0.45 ≤1.70 ≤0.020 ≤0.010 ≤0.06 ≤0.05 ≤0.06 ≤0.45
